Electrical parameter:

Diameter range:Φ4mm～Φ6mm
Contact diameter × number:8 pin
Rated Current (A):1.5
Insulation resistance:＞500MΩ
Protection level:IP65/67
Durability:＞500
Working temperature:-40℃～80℃
Connecting mode:insert connect

Material:

Housing, the insulating parts:A66
Copper needles:Copper Shell
Waterproof circle:Silica gel
Flammability rating:UL94-V0

●Compliance with D level or CAT 3e standard of EIA568B and ISO/IEC11801,RJ45 connec torscompatible CAT5e, data transfer rate reach 10GBIT/S
●Multi-style connecting modes: 1/4 bayonet connect (YT01), quickly plug/unplug(YT09/04)
●Applicable for harsh environments
●Cable jacket with solid diecasted shell and unique dual-clip-clip wire saddle
●Sheath of cable applicable for common RJ45 plugs
●Waterproof and non-waterproof design, protection level IP65 if waterproof and dustproof
●Electroplated shell against wind and rain
●Shielding system with high frequency noise immunity and electromagnetic interference protection

DIMENSION FIGURE:
