Description
| Fit panel aperture |
12/14/20/24/28/32/40 |
| temperature range | -45~+85℃ |
| Relative humidity | 40±2℃ 93% |
| working pressure | 2kPa |
| impact | Acceleration 245m/s2 |
| Rated voltage | 500V |
| Contact diameter(mm) | 1 | 1.5 | 2.5 | 3.5 | |
| Contact resistance(mΩ) | 5 | 2.5 | 1 | 0.5 | |
| Rated current(A) | 5 | 10 | 25 | 50 | |
